Created By  inflectra.adam Sunday, January 15, 2017
Rapise 4.0 supports the testing of Adobe AIR Flex applications using the Adobe Integrated Runtime (AIR). Rapise can test applications using a wide variety of different Flex controls and supports testing both Flex 3 and Flex 4 applications.

Rapise 4.0 supports the testing of Adobe Flex applications that are executed by the Adobe Flash Player inside the Internet Explorer, Mozilla Firefox or Google Chrome web browsers. Rapise can test applications using a wide variety of different Flex controls and supports testing both Flex 3 and Flex 4 applications.

[We have depreciated support for testing Adobe Flex/Flash applications in Rapise 5.0 and later, so this article is provided for use by existing customers]

Adobe AIR Applications

Rapise supports the testing of Adobe AIR applications. The Adobe Integrated Runtime (AIR) is a cross-platform framework for developing desktop and mobile applications that have rich graphic user interfaces and can be deployed across different platforms and devices (Windows, Mac, iOS, Android).

Rich Internet Applications using Adobe Flash

Rapise supports the testing of Flash and Flex applications using its built-in Flex libraries. Rapise can test web applications using a combination of HTML, Flash, Flex 3, Flex 4 and AIR components within a single application using a single test script.

Rapise can test Flash and Flex applications running in multiple browsers, including Internet Explorer, Mozilla Firefox and Google Chrome. Using the special FlexLoader, you don’t even need to modify your code to perform your testing.

Rapise supports the following Adobe Flex controls running in either Flash or AIR:

Control Type Matcher Rule (Flavor) Record Learn Comment
Button, LinkButton FlexButton Yes Yes
PopUpButton, PopUpMenuButton FlexPopUpButton Yes Yes
LinkBar FlexLinkBar Yes Yes
ToggleButtonBar, TabBar FlexToggleButtonBar Yes Yes
ButtonBar FlexButtonBar Yes Yes
Label, Text FlexLabel Yes Yes
RadioButton FlexRadioButton Yes Yes
List, HorizontalList FlexList Yes Yes
DateField FlexDateField Yes Yes
NumericStepper FlexNumericStepper Yes Yes
CheckBox FlexCheckBox Yes Yes
ComboBox FlexComboBox Yes Yes
DateChooser FlexDateChooser Yes Yes
TextArea, TextInput, RichTextEditor FlexTextArea Yes Yes
Tree FlexTree Yes Yes
DataGrid FlexDataGrid Yes Yes
SWFLoader FlexLoader Yes Yes
ProgressBar FlexProgressBar No Yes
HSlider, VSLider FlexSlider Yes Yes
ColorPicker FlexColorPicker Yes Yes
Image FlexImage Yes Yes
VideoDisplay FlexVideoDisplay Yes Yes
HDividedBox, VDividedBox FlexDividedBox Yes Yes
Accordion FlexAccordion Yes Yes
MenuBar FlexMenuBar Yes Yes
TabNavigator FlexTabNavigator Yes Yes
Panel, RadioButtonGroup, ViewStack FlexPanel Yes Yes
HBox, VBox, ApplicationControlBar FlexBox Yes Yes

Testing Adobe AIR Applications with Rapise

To test Flex applications running with Rapise, you must have Flex Builder installed. Link your application with FlexAdapter.swc (part of Rapise) and automation_agent.swc and automation.swc (part of Flex Builder).

The compiler arguments should look something like:

-include-libraries "C:/Program Files/Adobe/Flex Builder 3/sdks/3.2.0/frameworks/libs/automation_agent.swc" "C:/Program Files/Adobe/Flex Builder 3/sdks/3.2.0/frameworks/libs/automation.swc" "C:/Program Files (x86)/Inflectra/Rapise/Extensions/Flex/FlexAdapter/bin/FlexAdapter.swc"

Record and Playback using AIR

To record and playback tests for Adobe Flex applications being executed by Adobe AIR you need to run the application manually. E.g.:

"C:\Program Files\Adobe\Flex Builder 3\sdks\3.2.0\bin\adl.exe" C:\Program Files\Inflectra\Rapise\Samples\AdobeFlex\AUTFlexAIR\bin-debug\AUTFlexAIR-app.xml

Note: If you build your Flex AIR application with Flash Builder 4 or higher, you will need to turn on the "Generate Accessible SWF" option in the Flex Compiler Options.
